Product Features
Ultra-High Definition Resolution: Supports both 4K and 8K resolutions for intricate image detail.
Fine Pixel Pitch: A 1.8mm pixel pitch that is suitable for close viewing without pixelation.
Wide Color Gamut: Utilizes a wide color gamut for a more vibrant and true-to-life color palette.
High Refresh Rate: Ensures smooth motion in dynamic visuals with no lag, ideal for fast-moving videos.
Low Latency Processing: Optimized signal processing for real-time video playback with minimal delay.
Front Maintenance Design: Allows for easy and cost-effective maintenance, with quick access for troubleshooting and module replacement.
| Pixel Pitch | 1.86mm |
|---|---|
| LED Configuration | SMD1515 |
| Module Size | 320*160mm |
| Module Resolution | 172*86dots |
| Cabinet Size (WXHXD) | 640*480*58mm |
| Cabinet Resolution(WXH) | 160*120dots |
| Pixel Density | 289,050 dots/㎡ |
| Materail | Die-casting Aluminum |
| Cabinet Weight | 6KG |
| Brightness | ≥800cd/㎡ |
| View Angle | H 160°,W 160° |
| Best View Distance | ≥1.8m |
| Gray Scale | 16~18bit |
| Refresh Rate | ＞3840HZ |
| Frame changing frequency | 60fps |
| Input voltage | AC 86-264V/60Hz |
| Power Consumption (Max/Avg) | 600/300W/㎡ |
| Screen weight | 20kg/㎡ |
| MTBF | >10000 hrs |
| Service life | ≥100000 hrs |
| IP Rate | IP43 |
| Temperature | Working:﹣10℃～+65℃ or Storage:﹣40℃～+85℃ |
| Humidity | 10%-90%RH |
Product Application:
Commercial Advertising: Showcasing high-definition advertisements in shopping malls, hotels, and other commercial settings.
Control Rooms: Providing clear video monitoring in surveillance and traffic management centers.
High-End Conference Rooms: Enhancing the video conferencing experience in corporate settings.
Public Displays: Displaying high-definition images and videos in museums, exhibitions, and other public venues.
Stage Backdrops: Serving as a high-definition backdrop for concerts, TV show recordings, and other events.
FAQ
Q: What is the display quality of the P1.8 4K 8K LED Video Wall like?
A: The P1.8 LED Video Wall supports 4K and 8K resolutions, offering an ultra-high-definition viewing experience suitable for applications with the highest image quality demands.
Q: Is the video wall suitable for close-up viewing?
A: Yes, with a 1.8mm pixel pitch, the P1.8 LED Video Wall is designed for close-up viewing without the perception of pixelation.
Q: What are the brightness and contrast specifications of the video wall?
A: The P1.8 LED Video Wall features a brightness of up to 1200cd/m² and a contrast ratio of 10000:1, ensuring clear and distinct images in various lighting conditions.
Q: Does the video wall support front maintenance?
A: Yes, the P1.8 LED Video Wall is designed with front maintenance in mind, allowing for easy and efficient servicing and module replacement.
Q: What is the lifespan of the video wall?
A: The LED lifespan of the P1.8 LED Video Wall is up to 100,000 hours, ensuring long-term stable operation.
